Vinci LV BMS, Centralized topology

Description, configuration and ordering

Description

A single module performs all the BMS functions; it senses cell voltages through a number of tap wires.

The BMS consists of:

Item Info Function Qty
Vinci LV Battery Master Info Manage the battery 1
Power switch Info Precharge, disconnect the battery 1
Current sensors Info Sense the battery current 0~2
Cell wiring components Info Connection to the cells 1+
Communications adapters Info To a computer for monitoring (1)

To manage an array of batteries on a low voltage bus:

Item Info Function Qty
Array Master Info Manage the array 1
Block diagram
Centralized topology
